U440 Series

Product Features

Fabricated of #22 gauge stainless steel with a #4 satin finish

Uni-door construction available see model U4404

Removable waste can for easy maintenance

Product Specs

Body: Fabricated of #22 gauge stainless steel with #4 satin finish on all exposed areas.

Door: #22 gauge, one piece stainless steel secured to body by means of a full length heavy duty stainless steel piano type hinge.

Push Door: #22 gauge stainless steel self closing door.

Flange Fabricated of: #22 gauge stainless steel finished to match cabinet. One piece construction without miters or welds with 1/4" returns to wall.

Removable Waste: Heavy duty pre-plated steel with large service handle for easy servicing.

Back: Fabricated of stainless steel formed for rigidity with multiple welds to cabinet.

Locks: Pin tumbler commercial quality type, keyed like all other AJW cabinets.

Collars: Fabricated of #22 gauge stainless steel sized and finished to match cabinet, surf mount & semi-recessed.

Overall Size: 17 1/4"W x 30"H x 6 1/4"D

438mm x 762mm x 159mm

Wall Opening: 15 3/4"W x 28 1/2"H x 6"D

400mm x 724mm x 152mm

U440-S2: semi-recessed with 4" (102mm) wall opening

U440-S4: semi-recessed with 2" (51mm) wall opening

U440-SM: Surface Mounted

Waste Capacity: 6.5 gallons (.8 cu ft)

Installation Instruction

Coordinate installation with architect and contractor. Provide a wall opening 15 3/4"W x 28 1/2"H. Wall depth will vary will vary if collars are required. Open bottom door and remove waste from cabinet and insert in wall opening. Secure unit with proper f

U440

6.5 Gallon Waste Receptacle w/ Push Door - Recessed







Technical documents
