U480

Product Features

Fabricated of #22 gauge stainless steel with a bright polished finish

Waste receptacle is vanity mounted

Product Specs

Waste Chute: Fabricated of #22 ga stainless steel with a bright polished finish on all exposed surfaces seamless one piece construction.

Overall Size: 6 11/16" OD x 4 13/16"D

169mm x 122mm

Counter top Opening: 5 13/16" diameter

Installation Instruction

Provide an area on counter top at desired or specified location. Coordinate installation with architect contractor to avoid interference with pipes. Cut out opening for chute using proper tools. Fill in the underside of flange and around the area of the

U480

Round Waste Chute - Vanity Mounted





Technical documents
