U593

Product Features

Fabricated of #22 gauge stainless steel with a #4 satin finish

Waste receptacle has a 1.5 gallon capacity

Unit is equipped with a mounted storage shelf

Waste can is covered to maintain a sanitary environment

Product Specs

Cabinet Body: Fabricated of #22 ga stainless steel with #4 satin finish. Seamless construction with radius and hemmed edges.

Cabinet Back: Stainless steel welded to cabinet body with key hole mounting points.

Cover: Fabricated of #22 ga stainless steel #4 satin finish with embossed handles on each side and sloped top.

Hinge: Heavy duty, full length, stainless steel piano type hinge.

Shelf: Fabricated of #22 ga stainless steel with 1/2" bends, hemmed and ground smooth. Shelf supported by two stainless steel brackets. Can be mounted on either side of disposal.

International Graphic Symbol (IGS) available on request.

Overall Size: 17"W x 10"H x 4"D

431mm x 254mm x 102mm

Capacity: 1.6 gallons (.21 cu ft)

NDL-13: Waxed disposable liners. (50 per Case)

Installation Instruction

Provide an area at desired or specified location. Place unit on surface and transfer mounting points. Drill pilot holes and secure with proper fasteners. Install waxed liner.

U593

1.6 Gallon Sanitary Napkin Disposal w/ Mounted Shelf- Surface Mounted





Technical documents
